Industrial Waste Incinerators
The Incinerator Range
From a standalone unit to a fully integrated system with dry scrubbing and ceramic filtration, the range steps up with your emissions and site requirements.
Standard Incinerators
The standalone workhorse range, V23 to V500.
See overviewBiomass Incinerators
No diesel or gas supply required.
See overviewDry Scrubbing & APC
Acid gases, heavy metals and dioxins captured, with no water.
See overviewCeramic Filtration
Particulate control to 99.99%, at temperatures bag filters cannot survive.
See overviewStandard Incinerators for Medical, Hazardous and General Waste
Our standard incinerators are the units working all over the world: nine standalone models from the compact V23 to the high-capacity V500, processing from 10 to 370 kilograms of waste per hour. Each is a two-chamber machine that reduces medical, hazardous, animal, pharmaceutical and general waste to sterile ash at 850 to 1,100 degrees Celsius.
Units run on diesel, LPG, natural gas, dual fuel or waste oil, with manual or automatic feeding and continuous de-ashing, so operations do not stop to empty the chamber. Hospitals, mines, hotels and municipalities run the same proven platform, sized to their waste stream.
- 9 models: V23 to V500
- 10 to 370 kg/hr throughput
- Two-chamber combustion
- Diesel, gas, dual fuel or waste oil
- Manual or automatic feeding
- Continuous de-ashing
Biomass-Fuelled Incineration with Improved Emissions
For rural and remote sites without a reliable fuel supply, our biomass incinerators replace diesel or gas entirely, using biomass to reach and hold the required combustion temperature. The result is a waste incinerator that keeps running where fuel logistics would defeat a conventional unit.
Because the unit runs continuously rather than in stop-start batch cycles, no preheat is needed, biomass consumption is lower, and the more controlled combustion process improves emissions. The refractory, insulation and tall-stack design carry over from the standard range.
- No diesel or gas required
- Continuous operation, no preheat
- Lower biomass consumption
- Improved emissions control
- 7 to 15 m stack heights
- 1,500°C-rated refractory
Incinerators with Dry Scrubbing and Air Pollution Control
Where emission limits demand more than good combustion, our incinerators integrate dry gas scrubbing: a dosing agent, sodium bicarbonate and/or activated carbon, is injected directly into the flue gas stream, neutralising acid gases and adsorbing heavy metals and dioxins before the stack.
Unlike wet systems, our scrubbers use no water at all, so there is no effluent and no downstream water treatment to build, licence or maintain. Dry scrubbing forms the core of our air pollution control packages, combined with heat recovery and filtration as the project requires.
- No water, no effluent treatment
- Sodium bicarbonate or activated carbon
- Neutralises HCl, SO₂ and HF
- Captures Pb, Hg, dioxins and furans
- Integrated heat recovery options
- EU and South African compliance
Incinerators with Ceramic Filtration
For the lowest particulate emissions, flue gas is drawn through hollow ceramic filter elements that capture sub-micron particles, PM2.5 and PM10 at up to 99.99 percent efficiency, operating at temperatures where conventional bag filters fail.
The elements are self-cleaning by reverse pulse, and the scrubber dosing agent forms a reactive cake on the filter surface that extends the scrubbing reaction. Removing acid gases at high temperature also prevents dioxins reforming downstream, which is why the combination is recognised as Best Available Techniques under the EU Industrial Emissions Directive.
- Up to 99.99% filtration efficiency
- Sub-micron, PM2.5 and PM10 capture
- Self-cleaning reverse-pulse elements
- Operates where bag filters fail
- Prevents dioxin reformation
- Best Available Techniques (BAT)
Built to Perform Where Reliability Is Not Optional
Larger combustion chambers
Our chambers are larger than competitors' for a given capacity, giving a longer reaction time, more complete combustion and lower emissions.
Real-time combustion control
A fast-response oxygen analyser and controlled combustion air adjust conditions as they change, holding performance and cutting emissions.
Dry scrubbing and ceramic filtration
Acid gases, dioxins and sub-micron particulate are captured to 99.99%, using no water and meeting Best Available Techniques.
Engineered for a Wide Range of Waste Streams
Macrotec incinerators are in service across healthcare, industry, agriculture, mining, hospitality and municipal operations, from hospital incinerators handling medical waste to animal incinerators at abattoirs and farms.
Healthcare & medical waste
Hazardous waste & sludges
Animal & abattoir waste
Mining & remote camps
Hotels, lodges & resorts
Municipal & general waste
Emissions and Safety, Independently Certified
Our incinerators are engineered to meet the emission and safety requirements that govern our clients' operations, including the EU Industrial Emissions Directive (2010/75/EU), South African NEM:AQA, and WHO guidance for healthcare waste, with the applicable limits confirmed for each project. Our quality, environmental and occupational health and safety management systems are independently certified to ISO 9001, ISO 14001 and ISO 45001.
Tell Us About Your Waste Challenge
Tell us about your waste, energy or emissions challenge and our engineers will help you specify the right incinerator.
